15 kV Diagnostic DC Insulation Resistance Tester

$6,205

Quantity

Description

Offering CAT IV 1000 V, the Megger MIT1525-US (1002-909) is a compact, light 15 kV insulation resistance tester for the diagnostic testing and maintenance of high voltage electrical equipment. Enclosed in a tough case it is both smaller and lighter than its predecessor making it even easier to carry and store.

As well as measuring insulation resistance to 30 Teraohms, the MIT1525 also offers various diagnostic tests such as Polarization index, Dielectric Absorption Ratio, Step Voltage, Dielectric discharge and ramp testing.

Now equipped with two lithium ion fast rechargeable batteries, the MIT1525 has a large, clear, easy to read, display making it equally suitable for use in both bright sunlight and poorly lit environments. Information displayed includes resistance, voltage, leakage current, capacitance, battery status and time constant. In addition, the elapsed time of the test is displayed constantly removing the need for separate timer.

Product Details

Reference ME05278505MM

1 - MIT1525-US Insulation Resistance Tester (1002-909)
1 - Power Lead
3 - 10 ft. (3m) Test Leads with Large 15 kV Insulated Clips (1002-949)
1 - USB Cable
1 - PowerDB Lite Software
1 - Product Information CD

Product Features:

Ideal tester for original equipment manufacturers and industrial companies
Performs insulation resistance tests up to 15 kV with 30 teraohms maximum resistance
Offers full suite of test modes, including PI, DAR, DD, SV, and a ramp test
Dedicated voltmeter function measures AC/DC voltages from 30 V to 660 V
On-board memory logs up to 5.5 hours at 5 second intervals
USB interface allows for safe download of data to PC
Advanced memory functions with recall to screen and time/date stamping of results
Dual case design with tough outer case and fire-retardant inner case
Rechargeable li-ion batteries perform up to 4.5 hours continuous testing
Rated to IP65 for protection from moisture and dust
Large backlit display enables viewing of multiple test results
Intuitive user interface with easy rotary switch operation
Recorded temperature (measured by independent instruments) can be saved with test result
Maximum noise rejection of 6 mA offers high noise immunity
High current with 3 mA short circuit current
Safety rated at CAT IV 1000 V (maintained to 3000 m altitude)
