Hioki BT3562

The Hioki BT3562-01 benchtop battery tester supports simultaneous high-speed measurement of internal resistance and battery voltage for the ever-expanding production lines of increasingly larger lithium-ion low resistance batteries, and other battery packs for high voltage applications. The BT356201 can measure the voltage and resistance of coin-size to large-cell batteries up to 60V almost simultaneously due to their quick response time.

High Precision - High Resolution - Quick Response

Simultaneous Resistance & Voltage Judgments

Resistance and voltage can be simultaneously judged Hi/IN/Lo by independent comparators. Judgment results are provided on the display, beeper, and external I/O. The display allows confirming both results at a glance.

Composite Judgment Result Output

External I/O provides both separate and combined outputs of resistance and voltage judgment results, so composite results can be monitored.

Analog Output

The BT3562-01 provides analog output of resistance measurement values. This is convenient for combining recorded data from multiple locations or of various data types, such as for logging long-term measurements and for fuel cell evaluation.

• GPIB and Analog Output
• Measure high-voltage battery packs up to 60V
• Production line testing of high-voltage battery packs and battery modules
• Large (low-resistance) cell testing
• Choice of PC interfaces for full remote operation
• Note: The comparison threshold values depend on the battery manufacturer, type, and capacity, and these must be established by the user.
