Fluke Calibration 2700G  from Fluke
  • Fluke Calibration 2700G  from Fluke

Fluke Calibration 2700G

FL24455585FC
Fluke

Reference Pressure Test Gauge

$1,326
Quantity

Description

The Fluke Calibration 2700GBG100K Reference Pressure Test Gauge, -15 to 15 psi (-100 to 100 kPa) provides best-in-class measurement performance in a rugged, easy-to-use, economical package. Improved measurement accuracy allows it to be used for a wide variety of applications. The Fluke Calibration 2700G-BG100K Pressure Gauge is ideal for calibrating pressure measurement devices such as pressure gauges, transmitters, transducers, and switches. In addition, the Fluke Calibration 2700G-BG100K can be used as a check standard or to provide process measurements with data logging.

The Fluke Calibration 2700G-BG100K has an easy-to-use interface that allows you to configure the sampling rate, tare value, damping, and auto-off time interval as well as reset the min/max pressure. You can also view the remaining battery life. Select from 21 different standard engineering units, including bar, in H2O, kPa, MPa, and psi. In addition, the supervisor menu can be used to set one, custom engineering unit. To ensure against incorrect measurements, each of the above functions can be locked through the supervisor menu.

The Fluke Calibration 2700G-BG100K Reference Pressure Gauge can be combined with the Fluke Calibration P5500 series of comparison test pumps to make a complete pressure calibration system. The unique test port design of the Fluke Calibration P5500 series allows for hand tight connection of the 2700G without the use of PTFE tape.

Product Details
FL24455585FC
  • 1 - 1/4 NPT Female to 1/4 BSP Male Adapter
  • 1 - 1/4 NPT Female to M20X1.5 Adapter
  • 1 - Universal AC Power Supply
  • 1 - USB Communication Cable
  • 1 - Calibration Certificate of Traceability
  • 1 - User Manual

Product Features:

  • Range: -15 to 15 psi (-100 to 100 kPa)
  • Resolution: 0.001 psi (0.0001 bar)
  • Burst pressure: 45 psi (0.3 MPa)
  • Media compatibility: Any clean, dry non-corrosive gas
  • Accuracy: to 0.02% of full scale
  • Pressure connection: 1/4 in. NPT Male
  • Easy-to-use, rugged construction for reliable performance
  • For use with 700PTPK or 700HTPK Pump Kits for complete, portable pressure testing solution (up to 4 MPa/600 psi with PTP-1 pneumatic pump; up to 70 MPa/10000 psi with HTP-2 hydraulic pump)
  • For use with P5510, P5513, P5514, or P5515 Comparison Test Pumps for complete bench top pressure calibration solution
